Ultrasonic lace machine classification:

A. Integrate multiple models. Foreign models can be divided into a variety of models according to the specifications of flower wheel (flower wheel width, usually 25mm, 50mm and 65mm). When users process lace of different specifications, they can only buy a variety of models to solve the problem. CHJ ultrasonic lace machine can use another kind of flower wheel by replacing a few parts such as flower wheel pad and bracket, which is convenient for users. When using another specification of flower wheel, adjust the flower wheel pressure and generator output power accordingly.

B. Pneumatic instead of manual. After the realization of pneumatic control, the operator as long as push and pull reversing valve stem can realize the flower wheel up and down frequent operation, greatly reducing the labor intensity; On the other hand, by adjusting the throttle valve of the pneumatic system, the flower-wheel pressure can be easily adjusted in a large range.

C. Gas 2 liquid damping cylinder. The upper and lower cylinders of the flower wheel adopt gas-liquid damping cylinders, so that when the flower wheel is pressed down, the flower wheel is pressed down slowly due to the damping effect of the hydraulic damping cylinder in series with the flower wheel (small-hole throttling principle), which is not easy to damage the flower wheel and the tool amplitude lever, and improves the service life of the key parts.
